Todos los productos

Side wire terminals accept up to number 10 solid or stranded wire. Rated for fluorescent lighting fixtures typical in commercial applications. 0.050 in THK steel mounting strap zinc-plated for corrosion resistance. Ground screw terminal standard. 20 A, 120/277 V. Meets all UL 20 requirements, Federal Specifications WS 896.

Jandorf Switch, 125/250 V, 10/20 A, Wattage Rating: 0.5 hp, Number of Poles: 1, Switch Operation: On/Off, Contact Configuration: SPST, Terminal Type: Screw, Actuator Type: Toggle, White

Jandorf Switch, 12 VDC, 20 A, Number of Poles: 1, Switch Operation: On/Off, Contact Configuration: SPST, Terminal Type: Tab, Actuator Type: Toggle, Black/Silver

Side wire terminals accept up to number 10 solid or stranded wire. Rated for fluorescent lighting fixtures typical in commercial applications. 0.050 in THK steel mounting strap zinc-plated for corrosion resistance. Ground screw terminal standard. 20 A, 120/277 V. Meets all UL 20 requirements, Federal Specifications WS 896.

Side wire terminals accept up to number 10 solid or stranded wire. Rated for fluorescent lighting fixtures typical in commercial applications. 0.050 in THK steel mounting strap zinc-plated for corrosion resistance. Ground screw terminal standard. 20 A, 120/277 V. Meets all UL 20 requirements, Federal Specifications WS 896.

Small toggle switch blends with standard grade toggles. Larger contacts, backwire clamps on the side terminals. Side wire terminals accept up to number 10 solid wire. Back wire terminal accepts 12 ga or 14 ga wire. Heavy-duty cam action mechanism. Long, broad steel mounting strap, zinc-plated for corrosion resistance. Built-in wire stripper for #12 and #14 wire. Ground screw terminal, stippled line and ground contacts standard. Tri-combo head mounting and terminal screws. 15 A, 120/277 V. cULus listed, NOM certified.

Eaton Arrow Hart industrial grade toggle switch, #14-10 AWG, 30A, Flush, 120/277V, Back and side, Screw, Ivory, Load type: Motor Control, Fan, LED, Incandescent, ELV, MLV, CFL, Fluorescent, Halogen, Double-Pole, Dual-pole,Brass, Polycarbonate, Dimensions: 9.23 in L x 4.15 in W x 4.25 in H

Side wire terminals accept up to number 10 solid or stranded wire. Rated for fluorescent lighting fixtures typical in commercial applications. 0.050 in THK steel mounting strap zinc-plated for corrosion resistance. Ground screw terminal standard. 20 A, 120/277 V. Meets all UL 20 requirements, Federal Specifications WS 896.

Side wire terminals accept up to number 10 solid or stranded wire. Rated for fluorescent lighting fixtures typical in commercial applications. 0.050 in THK steel mounting strap zinc-plated for corrosion resistance. Ground screw terminal standard. 20 A, 120/277 V. Meets all UL 20 requirements, Federal Specifications WS 896.

Jandorf Switch, 125/250 V, 10/15 A, Number of Poles: 1, Switch Operation: Normally Off, Contact Configuration: SPST, Terminal Type: Screw, Actuator Type: Toggle

Eaton Wiring Devices Toggle Switch, 120, 277 VAC, 20 A, 1 Pole, Steel Contact, -40 to 65 deg C, Flush Mounting, PVC Housing Material, Light Almond, Dimensions: 1.3 in L x 0.902 in W x 4.2 in H

Jandorf Switch, 14 VDC, 21 A, 1 Pole, On/Off, SPST Contact Configuration, Tab Terminal, Toggle Actuator, Nylon Housing Material, Red

Jandorf Switch, 12 VDC, 20 A, Number of Poles: 1, Switch Operation: On/Off, Contact Configuration: SPST, Terminal Type: Tab, Actuator Type: Toggle, Red

Side wire terminals accept up to number 10 solid or stranded wire. Rated for fluorescent lighting fixtures typical in commercial applications. 0.050 in thick steel mounting strap zinc-plated for corrosion resistance. Ground screw terminal standard. Meets all UL 20 requirements, Federal specifications WS896.

Surface mount, side wire, Feed-through heavy-duty plastic construction switch for SPT cord, 10 A at 125 V, 5 A at 250 V.

Gardner® Bender switches are available in many different styles and sizes. They are used in countless applications, from basic on-off to Multi-function applications. Most of our electrical switches are suitable for marine, industrial or auto-motive applications. They are available in a variety of characteristics including actuator type, handle shape, body construction and size, terminal type, voltage rating, sealing properties and illumination. Gardner® Bender switches are leading the industry in quality and durability.

Start the engines, turn on the lights and flip on the fan with quality switches. This cater quality duck bill switch is designed for numerous applications. The off-on duck bill switch is made out of chrome and is extremely durable making it an ideal switch for varied uses. The duck bill has a wide, flat actuator and the terminal is 1/4 in. UL listed and CSA certified switch is designed for indoor use. All switches come in a variety of styles and functions.

Jandorf Switch, 125/277 V, 10/20 A, Number of Poles: 1, Switch Operation: On/Off, Contact Configuration: SPST, Terminal Type: Tab, Actuator Type: Toggle

Meets all UL 20 requirements. Shank is threaded 15 - 32 in, 32 in x 9/32 in long. Keyed shank, indicator plate and finishing nut furnished. Wire leads are 6 in long #18, stripped 3/4 in. Metal On/Off bat handle. Temperature rating -40 to 65 deg C.

Jandorf Switch, 12 VDC, 20 A, Number of Poles: 1, Switch Operation: On/Off, Contact Configuration: SPST, Terminal Type: Tab, Actuator Type: Toggle, Black

Longer, wider strap on toggle lighted switches provides 40% more contact area to wall board. Virtually eliminates floating installations. Industrial design cam action mechanism insures quiet switch action. Patented built-in wire stripper for #14 and #12 wire to speed installation. Unbreakable top and bottom housing eliminates call backs due to job site breakage. Patented built-in wire looper for pre-looping. Push-in terminals accept #14 solid wire only. Side wire terminals accept up to #10 solid or stranded wire.
